Xintex Propane Fume Detector with Alarm & Solenoid P-1BS-R

Detect propane leaks early and automatically shut off gas supply to prevent personal injury and possible explosions.

There are three (3) LED's located on the Display unit, as well as an LED for the Solenoid Valve status. The Green LED, located at the top, indicates that system is operational. The Yellow LED, located in the centre, indicates

The Red LED, located at the bottom, indicates a fume buildup of 20% of the Lower Explosive Limit (LEL) which is considered an alarm. The 68 dB Alarm Horn will sound when the Red LED is illuminated.

Specifications:

• Single Channel: Maximum of one Sensor
• Bezel Diameter: 2-3/16" (56 mm)
• Cutout: 2-1/16" (52 mm) Round hole
• Operating Voltage: 9-30V DC
• Nominal Current Draw: 55mA @ 12V DC
• Maximum Current Draw: 725mA @ 9V DC
• Reverse Polarity Protected: Yes
• Operating Temperature: -40 to 185°F (-40 to 85°C)
• Alarm Horn: 68 dB
